Empowering semiconductor manufacturing with precision and efficiency

Getting the most value from a semiconductor supply chain requires the ability to model and optimize the specific complexities of the industry. The Eyelit solution suite, comprised of Eyelit SIOP, Eyelit APS, and Eyelit MES, is uniquely positioned to cover all aspects of the semiconductor supply chain, including fabrication and backend facilities, fabless companies, and integrated device manufacturers.

Fabs require robust, up-to-date detailed information to manage thousands of process steps and tool interactions. Even fabless companies must track and optimize across a vast range of product attributes and supply chain permutations. This is why Eyelit has combined AI-driven Manufacturing Operations Management (MOM) with supply chain planning and scheduling in a single integrated suite. With the solution in place, semiconductor organizations can predict market demand, optimize the use of inventory and manufacturing capacity, whether internal or subcontracted, and maximize the throughput of capacity-constrained fabrication facilities.

Eyelit has more than two decades of proven semiconductor experience satisfying the needs of this complex industry. Supporting reentrant flows, multi-level genealogy from ingot to die, SEMI E-10 equipment state modeling, and IP-based access controls for multi-customer environments.

Differentiating Capabilities

Key Capabilities

Cost-effective precision manufacturing:

Enables manufacturers to achieve high-quality production with automation and Six Sigma processes, ensuring 99.99966% defect-free products.

Supports cleanroom operations

From small R&D facilities to large-scale fabs, Eyelit solutions optimize operations in cleanroom environments, managing the complex production of high-value semiconductor products.

Wafer fabrication and testing:

Provides tools for slicing, epitaxial growth, and testing of wafers, including stacked wafers and systems on a chip (SoC), ensuring quality and efficiency throughout the process.

Assembly and packaging
of integrated circuits
:

Enables precise control over dicing, assembly, and testing, ensuring seamless integration of components in advanced devices.

MEMS and Sensors:

Real-time tracking, data collection, and process control. Providing visibility into production performance and streamlining workflows for greater efficiency.

Handles multiple wafer sizes:

Manages the production of wafers from 75mm to 300mm in size, supporting fabs equipped with precision tools that handle a wide range of geometries and outputs.

Thousands of die per wafer:

Facilitates the high-volume production of thousands of die per wafer, maximizing output and efficiency in high-stakes production environments.

Enhanced semiconductor manufacturing processes:

Eyelit solutions are critical in optimizing processes such as wafer slicing, dicing, and assembly, improving overall production quality and throughput.
